BN-20 PROMOTION – Now through March 30th

VersaStudio BN-20
Desktop Inkjet Printer/Cutter
Was $8,495 Now $5,995*

Get Your Quote Started Today!

Please fill out this form to start your quote today!

Start building a t-shirt, poster, sticker, and decal graphics printing business, all from the comfort of your desktop. With the VersaSTUDIO BN-20, you can print, cut, and create high-quality graphics without the high price tag.

  • Easily the most versatile print device in its class— print and cut on a huge range of vinyl, films, and media
  • In addition to traditional graphics, you can create heat transfer graphics for jerseys, hoodies, bags and more
  • Legendary Roland DG machine reliability combines with exceptional image and color quality to give you the solution you need to succeed

Download Your VersaStudio BN-20 Brochure
Get your digital guide to all the features, applications, benefits and specifications of the Desktop Inkjet Printer/Cutter.


Click to watch the BN-20

Financing Available!


Specifications

ModelVersaStudio BN-20
Printing method / Cutting methodPiezoelectric inkjet / Grit roller feed
Acceptable mediaWidth – 5.9 to 20.3 in. (150 to 515 mm)
ThicknessPrinting: Maximum 39 mil (1.0 mm) with liner
Cutting: Maximum 16 mil (.4 mm) with liner
Roll WeightMaximum 13.2 lbs (6 kg)
Roll Outer DiamaterMaximum 5.9 in (150 mm)
Core Diamater2 in (50.8 mm)or 3 in (76.2 mm) cores
Printing/cutting width1Maximum 18.9 in (480 mm)
Ink cartridgesType
Ink Cartridges Colors5 Color – CMYK+Mt (Cyan, Magenta, Yellow, Black and Metallic Silver) or CMYK+Wh (Cyan, Magenta, Yellow, Black, and White)
4 Color – CMMYK (Cyan, Magenta, Yellow, Black)
Printing resolutionMax 1440 dpi
Blade OffsetFixed at 0.250 mm
Cutting speed0.4 (10 mm/s) to 5.9 in/s (150 mm/s)
Blade force30 to 300gf
Software resolution (when cutting)0.000984 in/step (0.025 mm/step)
Distance accuracy (when printing)2,3Error of less than ± 0.3 % of distance traveled, or ± 0.3mm (0.012 in), whichever is greater.
Distance accuracy (when cutting)2,4Error of less than ± 0.4 % of distance traveled, or ± 0.3mm (0.012 in), whichever is greater.
Repetition accuracy (When cutting)2,5±0.004 in (± 0.1mm) or less
Alignment accuracy for printing and cutting2,6±0.020 in (± 0.5mm) or less
Alignment accuracy for printing and cutting when reloading media2,7Error of less than ± 0.5% of distance traveled, or ± 0.012 in (3mm), whichever is greater
Print Heater Temperature8Fixed at 95o F (35oC)
ConnectivityUSB 2.0
Power-saving functionAutomatic sleep feature / AC 100 to 240V ± 10%, 1.5 A, 50/60 Hz
Power ConsumptionDuring Operation – Approx. 90 W
Sleep ModeApprox. 5.5 W
Acoustic Noise LevelDuring Operation – 62 dB (A) or less
During Standby42 dB (A) or less
Dimensions/Weight39.2″ W x 23″ D x 11.5″ H (995 W x 585 D x 291 H mm), 79.4 lbs (35 kg)
Operating Conditions
Power On
Temperature: 68o – 90o F (20 to 32o C), humidity: 35 – 80% RH (non condensing)
Power offTemperature: 41o – 104o F (5 to 40o C), humidity: 20 – 80% RH (non condensing)
Included ItemsPower cord, USB cable, blade, blade holder, Roland software Package9, Software RIP (VersaWorks), User’s Manual, etc

*1 The length of printing or cutting is subject to the limitations of the program.
*2 Using Roland specified media, loaded correctly, temperature: 25°C (77°F), humidity: 50 %RH, all pinch rollers are used, 25 mm or more for both right and left margins and 35 mm or more front margin, excluding expansion or contraction of the emdia, and all correction and adjustment functions of this machine have been made properly.
*3 Using Roland specified media, print travel of 1m.
*4 Using Roland specified media, cut travel of 1m.
*5 Range for assured repetition accuracy: Length 1,000 mm.
*6 Provided that media length is under 1,000 mm. Excluding possible shift caused by expansion/contraction of the media and/or by reloading the media.
*7 Using Roland specified media, data size: 1,000 mm in the media-feed direction, 480 mm in the carriage-movement direction. No lamination. Automatic detection of crop marks at 4 points when media is reloaded. Excludes the effects of skewed movement and of expansion and contraction of the media.
*8 Warm-up is required after power up. This may require 5 to 20 minutes, depending on the operating environment. The preset temperature may fail to be reached 35°C (95°F) depending on the ambient temperature and media width.
*9 Roland Software Package includes: Windows driver, OnSupport software, utility software and R-Works design software

Roland VersaWorks 6 System Requirements
Operating systemWindows® 10 (32/64-bit)
Windows® 8.1 (32/64-bit)
Windows® 7 Professional / Ultimate (32/64-bit)
CPUIntel® Core™2 Duo, 2.0 GHz or faster recommended
RAM2 GB or more recommended
Video card and monitorA resolution of 1,280 x 1,024 or more recommended
Free hard-disk space40 GB or more recommended
Hard-disk file systemNTFS format
Optical driveDVD-ROM drive
Other requirementsEthernet or USB port
Internet connection and web browser to use Roland@NET

Please note: Considering that you will be using software such as Illustrator, we recommend that you use as high performance computer as possible to reduce RIP processing time. We also recommend using a hard disk that has large enough capacity, as print files are often tens of GB in size (or larger) when data is high resolution.

* Terms and conditions. Promotion valid through March 31, 2021
